Monitor Audio SoundFrame 3 In-wall Speaker
$449.00 $499.00
Monitor Audio SoundFrame 3 In-wall Speaker
The SoundFrame series consists of three sizes of speakers that complement any room. SoundFrame 3 On-Wall is the most compact speaker of the three and it can be used on its own, as a rear to complement the SoundFrame 1 On-Wall and SoundFrame 2 On-Wall, or with a sub-woofer.
Individual images for the grille cloths can be selected from our library or bespoke speakers can be created using your own high resolution photographs. The cabinet frames are available in high gloss white and high gloss black lacquer.
The SoundFrames can be fitted either in-wall or on-wall and with or without a frame using the Frameless grilles option.
The SoundFrame 3 In-Wall has a 2-way configuration with a pivoting 1-inch tweeter module and a 4-inch C-CAM driver.
Technology
- Quick and easy installation.
- Slender 87 mm (3.5") cabinet depth.
- Choice of high gloss white or black lacquer frames.
- SoundFrame 3: 2-way configuration: a pivoting 1 inch tweeter module with a 4-inch C-CAM driver.
- High frequency attenuation +- 3 dB.
- Ultra-discreet on-wall/in-wall AV/audio system, suitable for any interior.
Optional Add on:
Monitor Audio SoundFrame Grille
Having picked the perfect mix of SoundFrame speakers for your music or home theatre system, and decided whether Black or White frames or Frameless works best for you, your final step is choose the grilles. These could be the standard black or white grilles which come with your product, or you can pick something from our grille library. Blend with your décor, or provide an artful contrast – our range of designs will help you find the look you’re after.
Specification
Frequency Response
75 Hz — 35 kHz
Sensitivity (1W@1M)
86 dB
System Configuration
2-Way
Drive Unit Complement
1 x 4" C-CAM mid-range driver
1 x 1" pivoting Gold Dome tweeter
Power Handling (RMS)
50 W
Maximum SPL
102.5 dBA
Recommended Amplifier Requirements
25 — 50W
Bass Alignment
Ported Box
Nominal Impedance
8 ohms
Crossover Frequency
3.2 kHz
Dimensions (Including Frame (H x W x D))
289 x 289 x 77.5 mm (113/8 x 113/8 x 3")
Depth From Wall
77.5 mm (3")
Weight (packaged)
2.76 kg (6 lbs)
Sold As
Single Unit
