Audio-Technica AT-VM750xSH Dual Moving Magnet Cartridge
$499.00
Audio-Technica AT-VM750xSH Dual Moving Magnet Cartridge
The Audio-Technica AT-VM750xSH Dual Moving Magnet Cartridge offers superior sound quality and durability. With its dual magnet design and Shibata stylus, it provides precise tracking and increased channel separation.
CALL FOR AVAILABILITIES
The AT-VMx series brings new warmth and realism to Audio-Technica’s premium dual moving magnet (MM) cartridge line, delivering an expansive soundstage that’s alive with musical detail.
Like all our MM cartridges, this updated design closely mirrors the cutter head used to make the vinyl master. It utilizes two magnets, positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. But the new VMx series also introduces material and design changes to further refine the sound, offering responsive playback that is especially sensitive to the dynamism of musical expression.
Easy to Install and Use
Each AT-VMx cartridge body has threaded inserts, enabling it to be mounted to a headshell with just two screws – no nuts required. And the redesigned stylus protector now includes a V-cut for easy reference of the stylus’s position when lowering it onto a record.
High Efficient Generator
The paratoroidal coil construction of the cartridge’s generator – two PCUHD coils per channel, one stacked behind the other – greatly improves electromagnetic performance, while a slight reduction in coil turns* enhances transient response for clean, lifelike sound.
*Compared to VM series cartridges.
Solid Boron Cantilever and Metal Body
The three premium VMx models (AT-VM760x, AT-VM750x, AT-VM745x) feature a solid boron cantilever. Naturally lightweight and rigid, boron transmits signals from the record groove faster than an aluminum cantilever. The result is more accurate sound reproduction that’s particularly noticeable on dynamic musical passages. The die-cast aluminum body reduces vibrations and resonance.

Interchangeable Styli
Since all AT-VMx series cartridges share the same body design and have a removable stylus, you can use almost any AT-VMNx replacement stylus* with any VMx cartridge for easy experimentatuioin with sound characteristics.
AT-VMN10xCB (conical/bonded/aluminum cantilever)
AT-VMN20xEB (elliptical/bonded/aluminum cantilever)
AT-VMN30xEN (elliptical/nude/aluminum cantilever)
AT-VMN40xML (microlinear/nude/aluminum cantilever)
AT-VMN45xML (microlinear/nude/boron cantilever)
AT-VMN50xSH (shibata/nude/boron cantilever)
AT-VMN60xSL (specil line contact/nude/boron cantilever)
All in the Design
AT-VMx - Vertical Dual Magnet Design
- The Vertical Dual Magnet (VM), design closely mirrors the cutter head used to make the vinyl master.
- The standard cutter head (used to record the vinyl master) uses two transducer coils, mounted perpendicular to each other at 45° from horizontal, to cut the channel: one in each wall of the 90 record groove.
- The AT-VMx cartridges use the same 90° V-Shape configuration as the cutter head. This way, the cartridge achieves accurate tracking, excellent channel separation, high definition of the stereo image and extreme clarity over the entire audio spectrum.
Specifications
Cartridge & Stylus | |
---|---|
Frequency Response | 20 to 27,000 Hz |
Channel Separation | 26 dB (1 kHz) |
Vertical Tracking Angle | 20° |
Tracking Force | 1.8 to 2.2 g (2.0 g standard) |
Stylus Construction | Nude Shibata |
Recommended Load Impedance | 47 k ohms |
Coil Impedance | 3.2 k ohms (1 kHz) |
DC Resistance | 750 ohms |
Coil Inductance | 480 mH (1 kHz) |
Output Voltage | 3.7 mV (1 kHz, 5 cm/sec.) |
Output Balance | 1.0 dB (1 kHz) |
Cantilever | 0.28 mm (0.011”) diameter solid boron |
Static Compliance | 20 × 10-6 cm/dyne |
Dynamic Compliance | 7 × 10-6 cm/dyne (100 Hz) |
Dimensions | 29.0 mm (1.1”) × 18.3 mm (0.72”) × 17.5 mm (0.69”) (H × W × D) |
Accessories Included | ・Cartridge installation screws** (M2.6) (10.0 mm (0.39”) × 2, 8.0 mm (0.31”) × 2, 5.0 mm (0.20”) × 2), Washer × 2, Non-magnetic screwdriver, Brush |
Threaded Hole | M2.6 × 2 |
Recommended Load Capacitance | 150 to 250 pF |
Replacement Stylus | AT-VMN50xSH* (sold separately) |
Stylus Curvature Radius | 2.7 × 0.26 mil |
Type | VM |
Weight | 8.8 g (0.31 oz) |
Notes | *The replacement stylus of this product is used for AT-VMx series products. In this series, we offer replacement styli with different stylus tip structures and point shapes. **Cartridge installation screws (5.0 mm (0.20”)) x 2 are used to secure the cartridge in the box at the time of purchase. Be sure to keep and not lose these after removing the cartridge from the box. For product improvement, the product is subject to modification without notice. |
